Moving magnet vs moving coil: which should you choose?
Both designs read the groove with a stylus on a cantilever; they differ in how they generate the signal. Moving magnet cartridges are higher-output and easy to live with, while moving coil cartridges trade convenience for lower moving mass and, often, greater resolution.
Unsure which suits your deck? Tell us your tonearm and phono stage and we will narrow it down before you audition.
MM & MC Selection
Moving magnet and moving coil designs to match every arm and phono stage.
Tonearm Matching
Compliance matched to effective mass for an ideal 8–12 Hz resonance.
Precision Alignment
Tracking force, overhang, azimuth, and VTA set with protractors and gauges.
Re-Tip & Rebuild
Stylus inspection, replacement, and factory rebuild arranged for you.
Phono Cartridges in Ottawa: A Buyer's Guide
A phono cartridge is the transducer at the end of the tonearm whose stylus reads the record groove and converts it to an electrical signal. It is one of the highest-leverage upgrades in an analogue system: a well-chosen, well-aligned cartridge sets much of a turntable's tonal character, detail, and tracking.
Key Takeaways
- Moving magnet (MM) cartridges offer higher output and replaceable styli; moving coil (MC) offer lower mass and detail but need more gain.
- Match the cartridge's compliance to your tonearm's effective mass so the resonance lands in the ideal 8–12 Hz range.
- Match output voltage to your phono stage's gain, and set loading impedance appropriately.
- A stylus lasts roughly 1,000–2,000 hours; inspect it periodically to protect your records.
- Range: Ortofon Vasari Red $450 to Dynavector XX2 MKII $2,850.
How Do You Match a Cartridge to Your Turntable?
Two compatibilities matter most. First, the tonearm: the cartridge's compliance should suit the arm's effective mass so the arm-and-cartridge resonance falls in the 8–12 Hz window. Second, the phono stage: the cartridge's output must match its gain — MC cartridges need considerably more gain than MM — with loading impedance set to taste. Tell us your turntable and electronics and we will recommend a cartridge that pairs well with both.
How Long Does a Stylus Last, and Can It Be Replaced?
A typical stylus lasts roughly 1,000 to 2,000 hours, varying with stylus profile, tracking force, and record cleanliness. A worn stylus dulls the sound and can damage records, so periodic inspection pays off. Many MM cartridges let you slide on a fresh stylus assembly, while most MC cartridges require a factory rebuild or replacement — both of which we can arrange.
Our Cartridges at a Glance
Choosing and fitting a cartridge is exacting work. Get in touch and we will recommend the right model for your arm and phono stage — and set it up with precision tools to protect your collection.
